2025 Volvo XC60
$47,050 - $58,100Starting MSRP
Onyx Black Metallic
Model Highlights
Fuel Economy
26 MPG Comb.
Transmission
Automatic w/OD
Body Type
SUV
Seatings
5 Seats
Overview
The Volvo XC60 comes in four all-wheel drive trims B5 Core, B5 Plus, B5 Ultra, and B5 Ultra Black Edition. The XC60 is powered by a 2.0L turbocharged engine that makes 247 horsepower mated to an 8-speed automatic transmission.
The most basic...
Build Your Own 2025 Volvo XC60
What’s new in the 2025 model?
The XC60 gets an updated trim lineup but otherwise carries over with minimal changes for 2025.
Looking for alternatives to the Volvo XC60?
Start Comparing NowColors
Exterior
Onyx Black Metallic
Specs
EPA Classification: Small SUV 4WD
Engine Order Code:
Engine Type: Intercooled Turbo Gas/Electric I-4
Displacement: 2.0 L/120
Fuel System: Gasoline Direct Injection
SAE Net Horsepower @ RPM: 247 @ 5400
SAE Net Torque @ RPM: 266 @ 1800
Drivetrain: All Wheel Drive
Trans Order Code:
Trans Type: 8
Trans Description Cont.: Automatic w/OD
Trans Description Cont. Again:
First Gear Ratio (:1): 5.06
Second Gear Ratio (:1): 3.07
Third Gear Ratio (:1): 2.05
Fourth Gear Ratio (:1): 1.52
Fifth Gear Ratio (:1): 1.26
Sixth Gear Ratio (:1): 1.00
Reverse Ratio (:1): 3.99
Final Drive Axle Ratio (:1): 3.33
Seventh Gear Ratio (:1): 0.79
Eighth Gear Ratio (:1): 0.66
Fuel Economy Est-Combined (MPG): 26
EPA Fuel Economy Est - City (MPG): 23
EPA Fuel Economy Est - Hwy (MPG): 30
Base Curb Weight (lbs): 4216
Dead Weight Hitch - Max Trailer Wt. (lbs): 3500
Dead Weight Hitch - Max Tongue Wt. (lbs): 350
Wt Distributing Hitch - Max Trailer Wt. (lbs): 3500
Wt Distributing Hitch - Max Tongue Wt. (lbs): 350
Maximum Trailering Capacity (lbs): 3500
Suspension Type - Front: Double Wishbone
Suspension Type - Rear: Multi-Link
Suspension Type - Front (Cont.): Double Wishbone
Suspension Type - Rear (Cont.): Multi-Link
Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 13.6
Rear Brake Rotor Diam x Thickness (in): 12.6
Drum - Rear (Yes or ):
Rear Drum Diam x Width (in):
Front Tire Order Code:
Rear Tire Order Code:
Spare Tire Order Code:
Front Tire Size: P255/40HR21
Rear Tire Size: P255/40HR21
Spare Tire Size: Compact
Front Wheel Size (in): 21 X 8.5
Rear Wheel Size (in): 21 X 8.5
Spare Wheel Size (in): Compact
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material: Steel
Steering Type: Rack-Pinion
Turning Diameter - Curb to Curb (ft): 37.4
Fuel Tank Capacity, Approx (gal): 18.8
Wheelbase (in): 112.8
Length, Overall (in): 185.4
Width, Max w/o mirrors (in): 78.7
Height, Overall (in): 65.4
Track Width, Front (in): 65.1
Track Width, Rear (in): 65.2
Min Ground Clearance (in): 8.5
Cargo Area Length @ Floor to Seat 1 (in): 68.8
Cargo Area Length @ Floor to Seat 2 (in): 37.8
Cargo Box Width @ Wheelhousings (in): 41.5
Cargo Box (Area) Height (in): 30.6
Cargo Volume to Seat 1 (ft³): 63.3
Cargo Volume to Seat 2 (ft³): 17.1
Passenger Capacity: 5
Passenger Volume (ft³): 103
Front Head Room (in): 38
Front Leg Room (in): 41.5
Front Shoulder Room (in): 58.2
Front Hip Room (in): 56.4
Second Head Room (in): 38
Second Leg Room (in): 38
Second Shoulder Room (in): 56.3
Second Hip Room (in): 55.4
Vehicle Name: Volvo XC60
Body Style: Sport Utility
EPA Greenhouse Gas Score: 5.0
Tons/yr of CO2 Emissions @ 15K mi/year: 6.8
Pricing
This model has 4 different trims.
MSRP
$58,100
Invoice
$55,776
Description
2.0 L/120, 247 @ 5400, Automatic w/OD
Fuel Economy
This model has 4 different trims.
City
23 MPG
Hwy
30 MPG
Combined
26 MPG
Description
2.0 L/120, 247 @ 5400, Automatic w/OD
