2024 Jeep Grand Wagoneer
$91,945 - $112,595Starting MSRP
Diamond Black Crystal Pearlcoat
Model Highlights
Fuel Economy
17 MPG Comb.
Transmission
Automatic w/OD
Body Type
SUV
Seatings
7 Seats
Overview
The Jeep Grand Wagoneer comes in five basic 4x4 trims, Grand Wagoneer, Series II, Obsidian, Series III and Series III Obsidian. The Grand Wagoneer is powered by a 3L twin turbo 6-cylinder with 510 horsepower mated to an 8-speed automatic...
Build Your Own 2024 Jeep Grand Wagoneer
What’s new in the 2024 model?
The 2024 Jeep Grand Wagoneer carries over with minimal changes.
Looking for alternatives to the Jeep Grand Wagoneer?
Start Comparing NowColors
Exterior
Diamond Black Crystal Pearlcoat
Midnight Sky
Baltic Gray Metallic Clearcoat
River Rock
Velvet Red Pearlcoat
Silver Zynith
Bright White Clearcoat
Specs
Engine Order Code: EFC
Engine Type: Twin Turbo Premium Unleaded I-6
Displacement: 3.0 L/183
Fuel System: Gasoline Direct Injection
SAE Net Horsepower @ RPM: 510 @ 5700
SAE Net Torque @ RPM: 500 @ 3500
Engine Oil Cooler: None
Drivetrain: Four Wheel Drive
Trans Order Code: DFR
Trans Type: 8
Trans Description Cont.: Automatic w/OD
Trans Description Cont. Again:
First Gear Ratio (:1): 4.71
Second Gear Ratio (:1): 3.14
Third Gear Ratio (:1): 2.11
Fourth Gear Ratio (:1): 1.67
Fifth Gear Ratio (:1): 1.28
Sixth Gear Ratio (:1): 1.00
Reverse Ratio (:1): 3.29
Trans PTO Access: No
Transfer Case Model: Electronic
Transfer Case Power Take Off: No
Seventh Gear Ratio (:1): 0.84
Eighth Gear Ratio (:1): 0.67
Fuel Economy Est-Combined (MPG): 17
EPA Fuel Economy Est - City (MPG): 14
EPA Fuel Economy Est - Hwy (MPG): 20
Cold Cranking Amps @ 0° F (Primary): 700
Cold Cranking Amps @ 0° F (2nd): 700
Maximum Alternator Capacity (amps): 230
Base Curb Weight (lbs): 6431
Gross Vehicle Weight Rating Cap (lbs): 7700
Gross Combined Wt Rating (lbs): 15000
Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
Dead Weight Hitch - Max Tongue Wt. (lbs): 500
Wt Distributing Hitch - Max Trailer Wt. (lbs): 8200
Wt Distributing Hitch - Max Tongue Wt. (lbs): 820
Maximum Trailering Capacity (lbs): 8200
Suspension Type - Front: Short And Long Arm
Suspension Type - Rear: Multi-Link
Axle Type - Front: Independent
Axle Type - Rear: Independent
Axle Ratio (:1) - Front: 3.92
Axle Ratio (:1) - Rear: 3.92
Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Brake ABS System (Second Line): 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 14.9
Rear Brake Rotor Diam x Thickness (in): 14.8
Drum - Rear (Yes or ):
Rear Drum Diam x Width (in):
Front Tire Order Code: TAR
Rear Tire Order Code: TAR
Spare Tire Order Code:
Front Tire Size: P285/45TR22
Rear Tire Size: P285/45TR22
Spare Tire Size: Full-Size
Front Wheel Size (in): 22 X 9
Rear Wheel Size (in): 22 X 9
Spare Wheel Size (in): Full-Size
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material: Steel
Steering Type: Rack-Pinion
Turning Diameter - Curb to Curb (ft): 38
Fuel Tank Capacity, Approx (gal): 26.5
Wheelbase (in): 123
Length, Overall (in): 214.7
Width, Max w/o mirrors (in): 83.6
Height, Overall (in): 75.6
Track Width, Front (in): 68.5
Track Width, Rear (in): 68.3
Min Ground Clearance (in): 10
Liftover Height (in): 31.9
Cargo Volume to Seat 1 (ft³): 94.2
Cargo Volume to Seat 2 (ft³): 70.9
Cargo Volume to Seat 3 (ft³): 27.4
Passenger Capacity: 7
Front Head Room (in): 41.3
Front Leg Room (in): 40.9
Front Shoulder Room (in): 66.1
Front Hip Room (in): 63.4
Second Head Room (in): 40
Second Leg Room (in): 42.7
Second Shoulder Room (in): 65.2
Second Hip Room (in): 63
Third Head Room (in): 39
Third Leg Room (in): 36.6
Third Shoulder Room (in): 64.4
Third Hip Room (in): 51.6
Vehicle Name: Jeep Grand Wagoneer
Body Style: Sport Utility
Body Code: S
EPA Greenhouse Gas Score: 3.0
Tons/yr of CO2 Emissions @ 15K mi/year: 10.4
Pricing
This model has 4 different trims.
MSRP
$112,595
Invoice
$110,805
Description
3.0 L/183, 510 @ 5700, Automatic w/OD
Fuel Economy
This model has 4 different trims.
City
14 MPG
Hwy
20 MPG
Combined
17 MPG
Description
3.0 L/183, 510 @ 5700, Automatic w/OD
