2023 Jeep Compass
$25,900 - $33,895Starting MSRP
Diamond Black Crystal Pearlcoat
Model Highlights
Fuel Economy
27 MPG Comb.
Transmission
Automatic w/OD
Body Type
SUV
Seatings
5 Seats
Overview
The 2023 Jeep Compass is offered in Sport, Latitude, Latitude Lux, Trailhawk and Limited trims. All trims are powered by the same turbocharged 2L 4-cylinder engine, producing 200 horsepower and 221 lb.-feet of torque. The engine features...
What’s new in the 2023 model?
For 2023, the Jeep Compass drops the front-wheel drive models, but otherwise carries over with minimal changes.
Looking for alternatives to the Jeep Compass?
Start Comparing NowColors
Exterior
Diamond Black Crystal Pearlcoat
Laser Blue Pearlcoat
Granite Crystal Metallic Clearcoat
Sting-Gray Clearcoat
Redline Pearlcoat
Billet Silver Metallic Clearcoat
Bright White Clearcoat
Specs
EPA Classification: Small SUV 4WD
Engine Order Code: EC1
Engine Type: Intercooled Turbo Regular Unleaded I-4
Displacement: 2.0 L/122
Fuel System: Gasoline Direct Injection
SAE Net Horsepower @ RPM: 200 @ 5000
SAE Net Torque @ RPM: 221 @ 1750
Drivetrain: Four Wheel Drive
Trans Order Code: DGD
Trans Type: 8
Trans Description Cont.: Automatic w/OD
Trans Description Cont. Again:
First Gear Ratio (:1): 4.72
Second Gear Ratio (:1): 2.91
Third Gear Ratio (:1): 1.86
Fourth Gear Ratio (:1): 1.42
Fifth Gear Ratio (:1): 1.22
Sixth Gear Ratio (:1): 1.00
Reverse Ratio (:1): 3.24
Final Drive Axle Ratio (:1): 4.40
Seventh Gear Ratio (:1): 0.79
Eighth Gear Ratio (:1): 0.64
Fuel Economy Est-Combined (MPG): 27
EPA Fuel Economy Est - City (MPG): 24
EPA Fuel Economy Est - Hwy (MPG): 32
Cold Cranking Amps @ 0° F (Primary): 500
Maximum Alternator Capacity (amps): 180
Base Curb Weight (lbs): 3840
Dead Weight Hitch - Max Trailer Wt. (lbs): 2000
Dead Weight Hitch - Max Tongue Wt. (lbs): 200
Wt Distributing Hitch - Max Trailer Wt. (lbs): 2000
Wt Distributing Hitch - Max Tongue Wt. (lbs): 200
Maximum Trailering Capacity (lbs): 2000
Suspension Type - Front: Strut
Suspension Type - Rear: Strut
Suspension Type - Front (Cont.): Strut
Suspension Type - Rear (Cont.): Strut
Brake Type: 4-Wheel Disc
Brake ABS System: 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 12
Rear Brake Rotor Diam x Thickness (in): 11
Drum - Rear (Yes or ):
Rear Drum Diam x Width (in):
Front Tire Order Code: TAF
Rear Tire Order Code: TAF
Spare Tire Order Code:
Front Tire Size: P215/65SR17
Rear Tire Size: P215/65SR17
Spare Tire Size: Full-Size
Front Wheel Size (in): 17 X 6.5
Rear Wheel Size (in): 17 X 6.5
Spare Wheel Size (in): Full-Size
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material: Steel
Steering Type: Rack-Pinion
Turning Diameter - Curb to Curb (ft): 35.3
Fuel Tank Capacity, Approx (gal): 13.5
Wheelbase (in): 103.8
Length, Overall (in): 173.4
Width, Max w/o mirrors (in): 73.8
Height, Overall (in): 64.8
Track Width, Front (in): 60.7
Track Width, Rear (in): 60.3
Min Ground Clearance (in): 8.6
Liftover Height (in): 29.7
Cargo Area Width @ Beltline (in): 42.1
Cargo Box Width @ Wheelhousings (in): 38.1
Cargo Box (Area) Height (in): 27.2
Cargo Volume to Seat 1 (ft³): 59.8
Cargo Volume to Seat 2 (ft³): 27.2
Passenger Capacity: 5
Passenger Volume (ft³): 99.6
Front Head Room (in): 39.2
Front Leg Room (in): 41.8
Front Shoulder Room (in): 56.7
Front Hip Room (in): 54.1
Second Head Room (in): 38.5
Second Leg Room (in): 38.3
Second Shoulder Room (in): 55.1
Second Hip Room (in): 49.2
Vehicle Name: Jeep Compass
Body Style: Sport Utility
Tons/yr of CO2 Emissions @ 15K mi/year: 6.6
Pricing
This model has 8 different trims.
MSRP
$33,895
Invoice
$33,458
Description
2.0 L/122, 200 @ 5000, Automatic w/OD
Fuel Economy
This model has 8 different trims.
City
24 MPG
Hwy
32 MPG
Combined
27 MPG
Description
2.0 L/122, 200 @ 5000, Automatic w/OD
