2025 GMC Sierra EV
$89,900 - $98,400Starting MSRP



Onyx Black
Model Highlights
Body Type
Truck
Seatings
5 Seats
Overview
The GMC Sierra EV is available as an all-wheel drive crew cab with a 5.75-foot box and two trims Denali w/5SC and Denali w/5SD. The Sierra EV is powered by two electric motors that produce 754 horsepower with a range of 440 miles.
The Sierra...

Build Your Own 2025 GMC Sierra EV
What’s new in the 2025 model?
The Sierra EV is an all-new electric truck that was added to the GMC lineup for 2025.

Looking for alternatives to the GMC Sierra EV?
Start Comparing NowColors
Exterior
Onyx Black
Deep Ocean Metallic
Moonlight Matte
Thunderstorm Gray
Dark Ember Tintcoat
Summit White
Specs
Number of Passenger Doors: 4
EPA Air Pollution Score:
Engine Order Code: EN0
Engine Type: Electric
Displacement:
Fuel System: Electric
SAE Net Horsepower @ RPM: 760
SAE Net Torque @ RPM: 785
Engine Oil Cooler:
Drivetrain: Four Wheel Drive
Trans Order Code: MF1
Trans Type: 1
Trans Description Cont.:
Trans Description Cont. Again:
First Gear Ratio (:1):
Second Gear Ratio (:1):
Third Gear Ratio (:1):
Fourth Gear Ratio (:1):
Fifth Gear Ratio (:1):
Sixth Gear Ratio (:1):
Seventh Gear Ratio (:1):
Eighth Gear Ratio (:1):
Reverse Ratio (:1):
Clutch Size (in):
Trans Power Take Off:
Trans PTO Access:
Transfer Case Model:
Transfer Case Gear Ratio (:1), High:
Transfer Case Gear Ratio (:1), Low:
Transfer Case Power Take Off:
EPA Fuel Economy Est - Hwy (MPG):
EPA Fuel Economy Est - City (MPG):
Fuel Economy Est-Combined (MPG):
EPA MPG Equivalent - City: 70
EPA MPG Equivalent - Hwy: 59
EPA MPG Equivalent - Combined: 64
Estimated Battery Range (mi): 460
Cold Cranking Amps @ 0° F (Primary):
Cold Cranking Amps @ 0° F (2nd):
Maximum Alternator Capacity (amps):
Maximum Alternator Watts:
Total Cooling System Capacity (qts):
Gross Axle Wt Rating - Front (lbs): - TBD -
Gross Axle Wt Rating - Rear (lbs): - TBD -
Curb Weight - Front (lbs): - TBD -
Curb Weight - Rear (lbs): - TBD -
Gross Vehicle Weight Rating Cap (lbs): 10500
Gross Combined Wt Rating (lbs):
Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
Dead Weight Hitch - Max Tongue Wt. (lbs): 500
Wt Distributing Hitch - Max Trailer Wt. (lbs): 10000
Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
Fifth Wheel Hitch - Max Trailer Wt. (lbs):
Fifth Wheel Hitch - Max Tongue Wt. (lbs):
Maximum Trailering Capacity (lbs): 10000
Suspension Type - Front: Adaptive Air Ride
Suspension Type - Rear: Adaptive Air Ride
Spring Capacity - Front (lbs):
Spring Capacity - Rear (lbs):
Axle Type - Front:
Axle Type - Rear:
Axle Capacity - Front (lbs):
Axle Capacity - Rear (lbs):
Axle Ratio (:1) - Front:
Axle Ratio (:1) - Rear:
Shock Absorber Diameter - Front (mm):
Shock Absorber Diameter - Rear (mm):
Stabilizer Bar Diameter - Front (in):
Stabilizer Bar Diameter - Rear (in):
Brake Type: Pwr
Brake ABS System:
Brake ABS System (Second Line):
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 14.5 x - TBD -
Rear Brake Rotor Diam x Thickness (in): 13.5 x - TBD -
Drum - Rear (Yes or ):
Rear Drum Diam x Width (in):
Front Tire Order Code: QMP
Rear Tire Order Code: QMP
Spare Tire Order Code: N/A
Front Tire Size: LT275/50R24
Rear Tire Size: LT275/50R24
Spare Tire Size:
Front Tire Capacity (lbs):
Rear Tire Capacity (lbs):
Spare Tire Capacity (lbs):
Revolutions/Mile @ 45 mph - Front:
Revolutions/Mile @ 45 mph - Rear:
Revolutions/Mile @ 45 mph - Spare:
Front Wheel Size (in): 24 x 9
Rear Wheel Size (in): 24 x 9
Spare Wheel Size (in):
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material:
Steering Type: Column-mounted electric power steering
Steering Ratio (:1), On Center: - TBD -
Steering Ratio (:1), At Lock: - TBD -
Turning Diameter - Curb to Curb (ft): 44.0 (2-Wheel Steer)/42.4 (4-Wheel Steer)
Turning Diameter - Wall to Wall (ft): - TBD -
Frame Type:
Fuel Tank Capacity, Approx (gal):
Aux Fuel Tank Capacity, Approx (gal):
Fuel Tank Location:
Aux Fuel Tank Location:
Wheelbase (in): 146
Length, Overall w/o rear bumper (in):
Length, Overall (in): 233.42
Width, Max w/o mirrors (in): 83.8
Height, Overall (in): 78.7
Overhang, Front (in): 36.5
Overhang, Rear w/o bumper (in): - TBD -
Front Bumper to Back of Cab (in): - TBD -
Cab to Axle (in): - TBD -
Cab to End of Frame (in): - TBD -
Ground to Top of Load Floor (in): - TBD -
Ground to Top of Frame (in): - TBD -
Frame Width, Rear (in): - TBD -
Ground Clearance, Front (in): 8.95
Ground Clearance, Rear (in): 8.95
Cargo Box Length @ Floor (in): 70.59
Cargo Box Width @ Top, Rear (in):
Cargo Box Width @ Floor (in): 65.35
Cargo Box Width @ Wheelhousings (in): 49.42
Cargo Box (Area) Height (in): 22.2
Tailgate Width (in): - TBD -
Cargo Volume (ft³): 57.5 (Bed)/11 (eTrunk)
Ext'd Cab Cargo Volume (ft³): - TBD -
Passenger Capacity: 5
Front Head Room (in): 43.85
Front Leg Room (in): 44.85
Front Shoulder Room (in): 63.98
Front Hip Room (in): 61.32
Second Head Room (in): 38.65
Second Leg Room (in): 44.32
Second Shoulder Room (in): 63.29
Second Hip Room (in): 60.84
Vehicle Name: GMC Sierra EV
Body Style: Crew Cab Pickup
Body Code: E63
EPA Greenhouse Gas Score:
Tons/yr of CO2 Emissions @ 15K mi/year:
Fuel Economy
This model has 2 different trims.
City
undefined MPG
Hwy
undefined MPG
Combined
undefined MPG
Description
, 760,
