2026 Cadillac XT5
$44,300 - $62,100Starting MSRP
Stellar Black Metallic
Model Highlights
Fuel Economy
21 MPG Comb.
Transmission
AUTO
Body Type
SUV
Seatings
5 Seats
Overview
The XT5 comes in three different trims: Luxury, Premium Luxury and Sport. The Luxury and Premium come in front-wheel drive (FWD) as standard, with all-wheel drive (AWD) available as an upgrade, while the Sport exclusively comes with AWD as...
Build Your Own 2026 Cadillac XT5
What’s new in the 2026 model?
The Cadillac XT5 receives minor package and trim updates but otherwise carries over with minimal changes for 2026.
Looking for alternatives to the Cadillac XT5?
Start Comparing NowColors
Exterior
Stellar Black Metallic
Opulent Blue Metallic
Emerald Lake Metallic
Radiant Red Tintcoat
Argent Silver Metallic
Crystal White Tricoat
Specs
EPA Classification: Sport Utility Vehicles
Number of Passenger Doors: 4
Engine Order Code: LGX
Engine Type: Gas V6
Displacement: 3.6L/- TBD -
Fuel System: Direct Injection
SAE Net Horsepower @ RPM: 310 @ 6600
SAE Net Torque @ RPM: 271 @ 5000
Drivetrain: All Wheel Drive
Trans Order Code: M3W
Trans Type: 9
Trans Description Cont.: Automatic
Trans Description Cont. Again:
First Gear Ratio (:1): - TBD -
Second Gear Ratio (:1): - TBD -
Third Gear Ratio (:1): - TBD -
Fourth Gear Ratio (:1): - TBD -
Fifth Gear Ratio (:1): - TBD -
Sixth Gear Ratio (:1): - TBD -
Seventh Gear Ratio (:1): - TBD -
Eighth Gear Ratio (:1): - TBD -
Ninth Gear Ratio (:1): - TBD -
Reverse Ratio (:1): - TBD -
Clutch Size (in): N/A
Final Drive Axle Ratio (:1): 3.49
Transfer Case Gear Ratio (:1), High:
Transfer Case Gear Ratio (:1), Low:
EPA Fuel Economy Est - Hwy (MPG): 26
EPA Fuel Economy Est - City (MPG): 18
Fuel Economy Est-Combined (MPG): 21
Cold Cranking Amps @ 0° F (Primary): - TBD -
Maximum Alternator Capacity (amps): 170
Total Cooling System Capacity (qts): - TBD -
Base Curb Weight (lbs): 4338
Dead Weight Hitch - Max Trailer Wt. (lbs): 1000
Dead Weight Hitch - Max Tongue Wt. (lbs): 100
Wt Distributing Hitch - Max Trailer Wt. (lbs): 1000
Wt Distributing Hitch - Max Tongue Wt. (lbs): 100
Maximum Trailering Capacity (lbs): 1000
Suspension Type - Front: MacPherson Strut
Suspension Type - Rear: Independent five-link
Suspension Type - Front (Cont.):
Suspension Type - Rear (Cont.): w/Coil Springs
Shock Absorber Diameter - Front (mm): - TBD -
Shock Absorber Diameter - Rear (mm): - TBD -
Stabilizer Bar Diameter - Front (in): - TBD -
Stabilizer Bar Diameter - Rear (in): - TBD -
Brake Type: Pwr
Brake ABS System: 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 13.6 x - TBD -
Rear Brake Rotor Diam x Thickness (in): 12.4 x - TBD -
Drum - Rear (Yes or ):
Rear Drum Diam x Width (in):
Front Tire Order Code: QNU
Rear Tire Order Code: QNU
Spare Tire Order Code: ZCD
Front Tire Size: P235/55R20
Rear Tire Size: P235/55R20
Spare Tire Size: Compact
Front Wheel Size (in): 20 x - TBD -
Rear Wheel Size (in): 20 x - TBD -
Spare Wheel Size (in): 18 x - TBD -
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material: Steel
Steering Type: Electric Rack & Pinion
Steering Ratio (:1), Overall: 15
Lock to Lock Turns (Steering): - TBD -
Turning Diameter - Curb to Curb (ft): 38.7
Turning Diameter - Wall to Wall (ft): N/A
Fuel Tank Capacity, Approx (gal): 22.0
Wheelbase (in): 112
Length, Overall (in): 189.6
Width, Max w/o mirrors (in): 74.9
Height, Overall (in): 66.1
Track Width, Front (in): 64.8
Track Width, Rear (in): 64.8
Min Ground Clearance (in): - TBD -
Rear Door Opening Height (in): - TBD -
Rear Door Opening Width (in): - TBD -
Liftover Height (in): - TBD -
Cargo Area Length @ Floor to Seat 1 (in): - TBD -
Cargo Area Length @ Floor to Seat 2 (in): - TBD -
Cargo Area Length @ Floor to Seat 3 (in):
Cargo Area Width @ Beltline (in): - TBD -
Cargo Box Width @ Wheelhousings (in): - TBD -
Cargo Box (Area) Height (in): - TBD -
Cargo Volume to Seat 1 (ft³): 63
Cargo Volume to Seat 2 (ft³): 30
Cargo Volume to Seat 3 (ft³):
Passenger Capacity: 5
Passenger Volume (ft³): 104.5
Front Head Room (in): 37.9
Front Leg Room (in): 41.2
Front Shoulder Room (in): 58.3
Front Hip Room (in): 56.1
Second Head Room (in): 36.6
Second Leg Room (in): 39
Second Shoulder Room (in): 56.3
Second Hip Room (in): 54.8
Vehicle Name: Cadillac XT5
Body Style: Sport Utility Vehicle
Tons/yr of CO2 Emissions @ 15K mi/year: 8.4
Pricing
This model has 5 different trims.
MSRP
$62,100
Invoice
$58,995
Description
3.6L/-, 310 @ 6600, AUTO
Fuel Economy
This model has 5 different trims.
City
18 MPG
Hwy
26 MPG
Combined
21 MPG
Description
3.6L/-, 310 @ 6600, AUTO
